Description
The ADT4100 combines a main unit, hair lysis solution, specialized reagent cards, triple-reagent testing kits, and a power adapter in a compact, field-ready design. Equipped with a built-in resident ID card reader compliant with GA 450-2013 standards, it ensures secure sample identification and handling. The analyzer features automated reagent card error detection, preventing invalid tests. It includes a 5-inch touchscreen interface and an integrated thermal printer for immediate result printing. High repeatability (CV ≤2%), strong linear correlation (r ≥0.98), and precise measurement accuracy (Δn ≤ ±8%) ensure reliable trace-level drug detection in hair samples.
Key Features:
-
Lightweight and portable: Main unit + adapter <0.75 kg; compact dimensions ≤255×100×60 mm.
-
Rapid analysis: Single test completed in ≤6 minutes.
-
Built-in ID card reader for secure sample tracking.
-
Reagent card error detection: Alerts for blank or improperly loaded cards.
-
Touchscreen interface: 5-inch display for easy operation.
-
Integrated thermal printer for instant results.
-
High accuracy and reliability: CV ≤2%, r ≥0.98, Δn ≤ ±8%.
-
Operable in field temperatures of 10–30°C.
-
Minimal inter-unit variation: relative deviation 1–6 Bis% <5%.
Application Range:
-
Forensic trace drug analysis in hair samples.
-
Law enforcement field drug detection.
-
Workplace or institutional drug monitoring programs.
-
Rapid on-site screening at checkpoints or testing facilities.
Technical Specifications / Parameters:
-
Model: ADT4100
-
Dimensions: ≤255 × 100 × 60 mm
-
Weight: <0.75 kg (main unit + adapter)
-
Display: 5-inch touchscreen
-
Analysis time: ≤6 minutes per sample
-
Operation temperature: 10–30°C
-
Repeatability: CV ≤2%
-
Linearity: r ≥0.98
-
Accuracy: Δn ≤ ±8%
-
Inter-unit deviation: 1–6 Bis% <5%
-
Components: Main analyzer, hair lysis solution, specialized reagent cards, triple-reagent test kits, power adapter, integrated ID card reader, thermal printer
